Product Highlights
NAS/SAN fusion storage, one controller implements two modes, no need for a dedicated NAS head.
Dual controllers, supporting up to 16 16G FC or 16 32G FC host interfaces and 8 10G SFP+ ports by default
Adopting the new generation storage ASIC chip as RAID engine, hardware accelerated RAID calculation
Supports dual MiniSAS fault-tolerant line expansion
The cache can support up to 512G cache (default DDR4 16GB)
Supercapacitor technology, when the external power supply is cut off, the cache data is written to the flash memory to ensure data security
Supports media scanning, hard disk cloning, hard disk copying and hard disk roaming
Support MAID green storage technology to increase disk life and reduce energy consumption
Local data replication services include snapshots and volume mirroring/copying, supporting up to an unlimited number of snapshots and mirror volumes
Support remote data replication service, supporting up to 16 replication source volumes; each replication source volume supports up to 4 pairs of replication; each system supports up to 64 pairs of replication
Supports automatic thin provisioning, effectively improving disk utilization and capacity expansion with zero downtime mechanism
Up to 864 hard disks can be installed by connecting expansion cabinets
Supports data deduplication
Support cache acceleration, and achieve more than 10 times increase in IOPS by configuring a small amount of SSD
Redundant and hot-swappable hardware components eliminate single points of failure
Product Features
Local copy service function
Local replication services include snapshots and volume mirroring/copying, which greatly help users protect data more efficiently. Through space-saving snapshot images, data can be easily restored when needed; and with full data backup, when the data volume is damaged, business can be quickly restored.
Remote replication service function
Remote replication provides data protection when the primary site fails, providing a continuous, non-destructive, host-independent solution for disaster recovery, data backup or long-distance data migration. Flexible deployment of synchronous or asynchronous replication to meet users’ different needs for cost, performance and data availability
Thin Provisioning Technology
Automatic thin provisioning allows users to allocate enough virtual capacity to applications when the actual capacity is less. The actual space is only occupied when data is written. Through the system’s dynamic capacity allocation, automatic thin provisioning can significantly improve storage utilization and greatly simplify capacity planning and management tasks)
Data Deduplication
Deduplication technology can eliminate a large amount of identical data in the system by comparing data hashes. In email systems, document management, and virtualized environments, it can greatly reduce duplicate files.
Data deduplication consumes storage CPU and memory resources and is not suitable for high IOPS environments.
efficiency
To promote environmental sustainability, the GS6300X v3 storage solution significantly saves energy costs while maintaining its performance. It is equipped with energy-saving designs such as high-efficiency energy-saving power supplies, dynamic cooling mechanisms and intelligent multi-level hard drive spin-down technology.
Automatic tiered storage
Automatic tiering technology uses virtual pool technology to enable storage to realize the automatic flow of SSD/SAS15K/SAS/10K/SATA 7.2K data. Automatic tiering depends on the customer’s QoS and data hotspot settings, and can store high-priority services and high-featured data in SSD as much as possible to achieve maximum storage performance.
Heterogeneous storage support
GS6300Xv3 series storage can realize storage heterogeneity, support storage of different brands to be inserted into GS6300X v3 series, and realize unified namespace and resource pool.
Host Port
Onboard host ports: 8 10GbE (SFP+) ports
More options: 4x 16Gb/s FC ports; 2 or 4x 32Gb/s FC ports; 2x 10GbE (SFP+) ports; 2x 10GbE (RJ-45) ports; 2x 25GbE (SFP28) ports; 2x 40GbE (QSFP+) ports; built-in virtualization capabilities
GS6300Xv3 has strong CPU processing power. The excess CPU processing power can be used to install customized applications for customers, improve system stability and reduce investment.
Multi-controller parallel expansion
GS6300Xv3 supports parallel expansion of multiple controllers in the system, supporting up to 24 controllers (12 units) running in parallel, and can achieve random distribution of system metadata and unified namespace in the entire cluster.
Flexible scalability
The dynamic expansion function of the GS6300Xv3 storage solution and the flexible drive type selection (SSD, SAS, NL SAS) allow users to meet current storage needs while facilitating the planning of future storage growth applications. For the exponential growth of capacity, by connecting expansion cabinets, up to 750 hard drives
Object Storage
Support object storage, including Alibaba Cloud, Amazon S3, OpenStack, etc.
manage
It is equipped with a variety of rich configuration storage management methods such as serial port, GUI, Web, etc. It can set, manage, monitor and adjust the operation of the disk array locally or remotely. The friendly browser-based graphical user interface fully describes the topology and operation status of the disk array, so that problems can be easily handled and the continuous operation of the system can be guaranteed.
