Product Features
Local copy service function
Local replication services include snapshots and volume mirroring/copying, which greatly help users protect data more efficiently. Through space-saving snapshot images, data can be easily restored when needed; and with full data backup, when the data volume is damaged, business can be quickly restored.
Remote replication service function
Remote replication provides data protection when the primary site fails, providing a continuous, non-destructive, host-independent solution for disaster recovery, data backup or long-distance data migration. Flexible deployment of synchronous or asynchronous replication to meet users’ different needs for cost, performance and data availability
Thin Provisioning Technology
Automatic thin provisioning allows users to allocate enough virtual capacity to applications when the actual capacity is less. The actual space is only occupied when data is written. Through the system’s dynamic capacity allocation, automatic thin provisioning can significantly improve storage utilization and greatly simplify capacity planning and management tasks)
Optical transmission protocol adaptation
The FC host interface board supports four modes: 8G 16G, 10G SFP+, and 10G FCoE. On the extended host interface board, you can define the optical interface board as one of the types at will, so that you can reduce investment and increase flexibility in the actual business model.
efficiency
To promote environmental sustainability, the GS6324M storage solution significantly saves energy costs while maintaining its performance. It is equipped with energy-saving designs such as high-efficiency energy-saving power supplies, dynamic cooling mechanisms and intelligent multi-level hard drive spin-down technology.
Flexible scalability
The dynamic expansion function of the GS6324M storage solution and the flexible drive type selection (SAS, NL SAS, SATA) allow users to meet current storage needs while facilitating the planning of future storage growth applications. For the exponential growth of capacity, up to 640 hard drives can be connected by connecting expansion cabinets.
manage
It is equipped with a variety of rich configuration storage management methods such as serial port, GUI, Web, etc. It can set, manage, monitor and adjust the operation of the disk array locally or remotely. The friendly browser-based graphical user interface fully describes the topology and operation status of the disk array, so that problems can be easily handled and the continuous operation of the system can be guaranteed.
Storage Virtual Server/Storage Virtual Machine
There are many computing resources in storage that are not being utilized. Therefore, PowerLeader virtualizes the storage controller to create one or more virtual machines on which customers can install operating systems and applications.
SAN service + customer application virtualization can reduce part of the customer’s investment, and at the same time some specific applications can make customers more stable and secure.
Powerleader is developing similar VM migration software, which will make it easier and faster for you to replace storage and migrate data in the future.
Product Highlights
Dual controllers, supporting up to 16 10/1G iSCSI, 16/8G FC, host interfaces
The FC host interface adopts protocol adaptation and can be configured in 8G, 16G, 10G SFP+, and 10G FCoE modes according to your needs.
Storage supports server virtualization, which utilizes excess computing resources in storage, virtualizes servers, installs operating systems and client applications on storage, and reduces client server requirements.
Adopting the new generation storage ASIC chip as RAID engine, hardware accelerated RAID calculation
Supports dual MiniSAS fault-tolerant line expansion
The maximum cache size can be up to 256GB
Supports supercapacitor + Flash or BBU + Flash technology. When the external power supply is cut off, the cached data will be written to the flash memory to ensure data security.
Supports media scanning, hard disk cloning, hard disk copying and hard disk roaming
Support MAID green storage technology to increase disk life and reduce energy consumption
Local data replication services include snapshots and volume mirroring/copying, supporting up to 4096 snapshots and 256 mirror volumes
Support remote data replication service, supporting up to 16 replication source volumes; each replication source volume supports up to 4 pairs of replication; each system supports up to 64 pairs of replication
Supports automatic thin provisioning, effectively improving disk utilization and capacity expansion with zero downtime mechanism
Up to 640 hard disks can be installed by connecting expansion cabinets
Redundant and hot-swappable hardware components eliminate single points of failure
