Atlas 200I SoC A1 core board

Call for Price

Atlas 200I SoC A1 is a core board for the edge inference server market, providing “basic general computing power + super AI computing power”. The core board is in the form of a full-height and full-length (10.5-inch) PCIe standard card. It can be adapted to 1U/2U chassis and supports customers to develop their own brand machines. It can be widely used in OCR recognition, target recognition, search recommendation, content review, etc. Many AI application scenarios.

Highly integrated

Integrate AI, CPU, memory, DVPP, task scheduler, etc.

Super performance

Provides a maximum of 176 TOPS INT8 computing power

Provides a maximum of 88 TFLOPS FP16 computing power

Flexible expansion

Can support computing power expansion to meet richer computing power needs

Technical specifications

model Atlas 200I SoC A1
Product form Full height and full length (10.5 inches) PCIe standard card form core board
AI computing power 88TFLOPSFP16

176TOPSINT 8

Memory specifications LPDDR4X, 48 GB, total bandwidth 204.8 GB/s, ECC support
processor Ascend 310 series AI processor
Codec capabilities Support H.264/H.265 Decoder hardware decoding, 128 channels of 1080P 30FPS or 16 channels of 4K 60FPS

Support H.264/H.265 Encoder hardware encoding, 24 channels of 1080P 30FPS or 3 channels of 4K 60FPS

JPEG decoding capability 4K 512FPS, encoding capability 4K 256FPS, maximum resolution: 8192×8192

Storage interface The onboard eMMC
supports up to 4 direct SATA 3.0 expansion interfaces.
PCIe interface Supports up to 16 lane PCIe 4.0 interface, rate is downward compatible with 3.0/2.0/1.0

Supports up to 5 PCIe controllers, configurable as PCIe x16 or 2*PCIe x8 or PCIe x8+2*PCIe x4 or PCIe x8+4*PCIe x2

Supports up to 8 xGE Serdes interfaces with a rate of 10.3125Gbps

Supports 4 SATA 3.0 interfaces, backward compatible with SATA 2.0, SATA 1.0

Maximum power consumption of the entire board 140W
Working temperature 0℃ ~ 50℃ (41℉ ~ 104℉)
structure size 267 mm (length) * 112 mm (height)
